H-起升高度Hoistingheight

　　V1-起升速度Hoistingspeed

　　V2-小车运行速度Travelingspeedoftrolley

　　V3-大车运行速度Travelingspeedofcrane

　　L1-起重机左极限Leftlimitofcrane

　　L2-起重机右极限Rightlimitofcrane

　　C1-起重机两端极限Minimumlimitofbothends

　　C2-起重机顶部极限Minimumlimitoftopofcrane

　　S-起重机跨度Cranespan

　　H1-起重机小车钩心到顶部的距离Distancebetweencoreofhookanditstop

　　H2-起重机小车的高度Heightoftrolley

　　H3-起重机底部到大车轨道面的距离Distancebetweenthebottomofcraneandcranerailplane

　　H4-起重机缓冲器到大车轨道面的距离Distancebetweenbufferofcraneandcranerailplane

　　H5-起重机顶部到大车轨道面的距离Distancebetweenthetopofcraneandcranerailplane

　　W-起重机两个车轮之间的距离Distancebetweentwooutmostwheelsofcrane

　　W1-起重机一角外两个车轮之间的距离Distancebetweentwooutmostwheelsofonecornerofcrane

　　W2-起重机台车两个车轮之间的距离Distancebetweentwowheelsoftrolley

　　B-起重机外车轮距离缓冲器端部之间的距离Distancefromtheoutmostwheeltoendsofbuffer

　　b-起重机端部距离大车轨道之间的距离Distancefromendstorailofcrane

　　G-起重机整车的重量Overallweightofcrane

　　K-起重机大轮压Maximumwheelpressureofcrane

　　P-起重机总的功率Totalpowerofcrane

Selection instructions

1. This product series table only lists the basic specifications of commonly used cranes, with standard spans for working level A5 (FEM2m), and indoor cranes without auxiliary hooks. Customers can make corresponding requests as needed.

2. This series can also add auxiliary lifting mechanisms and double the speed during light loads. Generally, the ratio of main to auxiliary is 4:1, which can also be set according to customer requirements. If a prisoner sets up a secondary hook, the total weight and wheel pressure of the crane will increase.

3. The dimensions, weight, and wheel pressure in the table are provided as reference for customers when placing orders. If the customer's requirements change, such as work level, speed, and lifting height, the corresponding parameters, dimensions, weight, wheel pressure, etc. will also change. The actual parameters, quality, and wheel pressure shall be subject to the requirements of the contract.

4. The lifting speed listed in the table, as well as the speed of the crane and trolley, are standard values that can be adjusted according to customer needs.

5. Technical parameters and dimensions may change due to technological improvements or upgrades. If you have any questions, you can contact the company's technical department.
